Kripal DZ47-125 1P miniature circuit breaker (MCB)

Model: DZ47

In Stock

~~₨ 1,499~~ ₨ 1,125

In Stock

Add to wishlist Compare

Other people want this. 237 people have this in their carts right now.

Categories: Circuit Breakers, Electronics & Accessories, MCB AC Circuit Breaker, Solar Equipment Brand: Kripal

Description

The KRIPAL DZ47 1P MCB is a single-pole miniature circuit breaker designed to provide reliable protection against overload and short-circuit faults in electrical circuits. It is suitable for use in residential, commercial, and light industrial installations. This breaker ensures the safe operation of electrical systems by automatically disconnecting the circuit when abnormal current conditions occur.

Key Features:

Type: Miniature Circuit Breaker (MCB)
Pole: 1 Pole (1P)
Rated Current: 1A to 63A (varies by model)
Rated Voltage: 230/240V AC
Breaking Capacity: 6kA
Trip Curve: Type C or D (optional)
Standard Compliance: IEC/EN 60898-1
Installation: DIN rail mounting
Indicator: ON/OFF status indicator
Housing Material: Flame-retardant thermoplastic
Application: Suitable for lighting, distribution, and control circuits

Description Summary:

The KRIPAL DZ47 1P MCB offers compact design, high breaking capacity, and dependable protection for single-phase circuits. It is ideal for circuit protection in homes, offices, and small-scale electrical systems.

Here are typical specifications for the single-pole version of the Kripal DZ47 series MCB (model “DZ47-63 / 1P” for example) — you’ll want to check the exact label on your unit for the exact rating. Zhejiang KRIPAL Electric Co., Ltd.+2shanghailingrui.en.made-in-china.com+2

Parameter	Typical Value
Rated current (In)	1 A, 2 A, 3 A, 4 A, 6 A, 10 A, 16 A, 20 A, 25 A, 32 A, 40 A, 50 A, 63 A Zhejiang KRIPAL Electric Co., Ltd.+1
Number of poles	1 P (also versions 2P, 3P, 4P exist) Zhejiang KRIPAL Electric Co., Ltd.+1
Rated voltage (Un)	AC 230/240 V for 1P; up to 400 V AC for multi-pole versions shanghailingrui.en.made-in-china.com+1
Rated frequency	50 Hz (also 50/60 Hz in some listings) zjkripal.en.made-in-china.com+1
Breaking / short-circuit capacity (Icn)	4.5 kA or 6 kA (depending on rating) for 1P versions shanghailingrui.en.made-in-china.com+1
Tripping characteristics / curves	Curves B, C or D (selectable) Zhejiang KRIPAL Electric Co., Ltd.+1
Operating temperature range	e.g., −5 °C to +40 °C for some versions shanghailingrui.en.made-in-china.com
Protection degree (after installation)	e.g., IP20 for some versions Zhejiang KRIPAL Electric Co., Ltd.
Compliance / standard	Conforms to IEC/EN 60898 (for domestic/residential use) shanghailingrui.en.made-in-china.com+1

Notes / Tips:

Make sure you select the correct current rating (e.g., 16 A, 20 A etc) for your circuit.
The curve type (B/C/D) matters: e.g., C-curve is common for mixed loads, D-curve is for high inrush loads.
Confirm the actual breaking capacity labelled on your unit — sometimes lower versions have 4.5 kA, higher versions 6 kA or more.
Ensure it matches the system voltage and is installed with proper wiring/cable size for the rated current.
If you tell me the exact model number printed on your breaker (e.g., “DZ47-63/1/ C20”) I can look up the exact datasheet for that one.
